95km/h
Top Speed
150 km
Range
*2 Batteries
6.3 KW
Peak Power
40 KG
Maximum Load
* Complete vehicle renovation design, intelligent system linkage deployment, customized complete solution (with minimum order quantity)
HIGHLY EFFICIENT & ECONOMICAL
The centre motor generates 6.2 kW of power at a top speed of 95 km/h. Acceleration from 0 to 60 km/h in 6 seconds.
IN DOUBLE PACK
With an optional second battery, the range can be up to 161 km.
Maximum Load
The luggage carrier is reinforced, rustproof and can carry a load of up to 40 kg. This offers the possibility to mount rear boxes with a maximum capacity of 200 litres.
Big seat cushion
The large and soft seat ensures fatigue-free and comfortable riding on longer journeys.
Intelligent display
The EK3DS can be started with a swipe of the finger on the display. The display also shows all the necessary information that is importantduring the journey.
Ingenious space concept
The large foot board and wide seat are ergonomically designed. Upper body and legs are relaxed. This means that the EK3DS offers a more comfortable riding experience.
Product Specification
 | |  | | |||||
| PERFORMANCE | EK1 DS | EK3 DS | ||||||
| Top Speed | 45km/h | 95km/h | ||||||
| Range | 166km（with 2 batteries) | 150km（with 2 | ||||||
| DIMENSION | ||||||||
| L*W*H | 1900mm*690mm *1130mm | 1900mm*690mm *1130mm | ||||||
| Saddle Height | 780mm | 780mm | ||||||
| Ground Clearance | 125mm | 125mm | ||||||
| Wheelbase | 1310mm | 1310mm | ||||||
| Weight(G.W) | 92kg（without battery） | 103kg（without battery） | ||||||
| POWERTRAIN | ||||||||
| Motor | Hub Motor | Mid Motor | ||||||
| Controller | FOC | FOC | ||||||
| Max Power | 3.0kW | 6.3kW | ||||||
| Continue Rated Power | 2.0kW | 4.0kW | ||||||
| Battery | 72V，36Ah（optional with second battery） | 72V，36Ah*2 | ||||||
| Charging Time（8A） | ≈4.5h | ≈4.5h*2 | ||||||
| Ride Mode | 1/2/3/R | 1/2/3/R | ||||||
| CHASSIS | ||||||||
| Brake System | Disc Brake | CBS+disc Brakes | ||||||
| Wheels | Tire | 100/80 R14 | Tire | 100/80 R14 | ||||
| 110/70 R13 | 110/70 R13 | |||||||
| Rim | Aluminium Alloy | Rim | Aluminium Alloy | |||||
| SMART&FEATURES | ||||||||
| Safety System | GPS+Transaction Alarm | GPS+Transaction Alarm | ||||||
| Touch-start Display | ● | ● | ||||||
| All-around LED Lights | ● | ● | ||||||
| Keyless Go | ○ | ● | ||||||
